M3 Vital Signs Monitor User Manual NIBP Monitoring (Optional)
- 66 -
DIA 10 mmHg ~ 100 mmHg
MAP 20 mmHg ~ 110 mmHg
Default NIBP alarm limits:
ADU (mmHg)
PED (mmHg)
NEO (mmHg)
Lower
Limit
Upper
Limit
Lower
Limit
Upper
Limit
Lower
Limit
Upper
Limit
SYS
90
160
70
120
40
90
DIA
50
90
40
70
20
60
MAP
60
110
50
90
25
70
When the monitor is configured to NIBP only measuring mode, the PR is displayed in the
ALARM SETUP menu.
The range of PR alarm limit:
Max. Upper Limit (bpm)
Min. Lower Limit (bpm)
Step (bpm)
PR
240
40
1
Default PR alarm limit:
Max. Upper Limit (bpm)
Min. Lower Limit (bpm)
Step (bpm)
ADU
120
50
1
PED
160
75
1
NEO
200
100
1
9.6.2 Alarm Information and Prompts
Physiological alarms:
Message
Cause
Alarm Level
NS HIGH
NIBP SYS measuring value is above upper alarm limit.
Medium
NS LOW
NIBP SYS measuring value is below lower alarm limit.
Medium
ND HIGH
NIBP DIA measuring value is above upper alarm limit.
Medium
ND LOW
NIBP DIA measuring value is below lower alarm limit.
Medium
NM HIGH
NIBP MAP measuring value is above upper alarm limit.
Medium
NM LOW
NIBP MAP measuring value is below lower alarm limit.
Medium
