M3 Vital Signs Monitor User Manual TEMP Monitoring (Optional)
- 72 -
Physiological alarms:
Message
Cause
Alarm Level
TEMP HIGH
Measuring value of TEMP is above upper alarm limit.
Medium
TEMP LOW
Measuring value of TEMP is below lower alarm limit.
Medium
Technical alarms:
Message
Cause
Alarm Level
What to do
Temp COMM
STOP
TEMP module
failure or
communication
failure.
High
Stop using measuring function
of TEMP module; notify
biomedical engineer or
Manufacturer’s service staff.
Temp exceed
limit
The TEMP value is
beyond the range of
35.5 C ~ 42 C
Medium
Put the sensor into the sensor
bracket, take it out and
measure again.
No TEMP
SENSOR
TEMP sensor is not
connected to the
TEMP module.
Low
Connect the sensor and the
monitor well, and measure
again.
Ambient temp
too high
The Sensor
temperature is higher
than +40 C
Low
Put the sensor into the sensor
bracket, measure again after
the ambient temperature
reaches normal value.
Ambient temp
too low
The Sensor
temperature is lower
than +10 C
Low
PROBE ERROR
The probe cannot be
identified.
Medium
Put the sensor into the sensor
bracket, take it out and
measure again. If the problem
persists, stop using measuring
function of TEMP module;
notify biomedical engineer or
Manufacturer’s service staff.
Warm-up error
Malfunction in the
warm-up circuit
Medium
