SE-1201 Electrocardiograph User Manual Technical Specifications
- 122 -
A1.3 Physical Specifications
Dimensions 361mm×262mm×135mm (91.6in×66.5in×34.3in)
Weight Approx. 4.2 kg (1.9 lbs) (Excluding recorder paper and battery)
Display 800×480 TFT LCD Screen
A1.4 Power Supply Specifications
Operating Voltage = 100V-240V~
Operating Frequency = 50Hz/60Hz
Mains Supply:
Input Current = 0.9-0.4A
Rated voltage = 14.8V
Rated capacity = 2200mAh
When the battery is fully charged, SE-1201 can work
normally about 4 hours, and it can continually print about
1.5 hours in the MANU mode or print about 300 ECG
reports of 3×4+1R in the auto mode.
Charge mode: Constant current/voltage
Charge current (standard) = 0.45 C
5
A (1000mA)
Charge voltage (standard) = 16.8V
Final discharging voltage = 12V
Necessary Charge time: 3 hours
Li-ion Battery Pack:
Cycle life ≥ 300 times
Fuse:
T3.15AH 250V Ø5×20
