SE-1201 Electrocardiograph User Manual Introduction
- 10 -
Symbol Name Explanation
A
Mains supply
indicator
When the device is powered by the mains supply,
this indicator is lit.
B Battery indicator
When the device is powered by the battery, this
indicator is lit.
C
Battery recharging
indicator
When the device is powered on, the indicator
flashes for a few seconds.
When the battery is being recharged, this indicator
is lit.
2.2 Keyboard and Keys
Figure 2-2 SE-1201 Keyboard
