SE-1201 Electrocardiograph User Manual Introduction
- 11 -
Name Explanation
A Function Key Press to select menu functions on the screen.
B Gender Key
Press to select the gender for the patient when Gender is
selected in the Patient Information Setup window.
C Age Group Key
Press to select the age group on the main screen when you set
Age to Age Group in the Patient Information Setup window.
D Delete Press to erase characters.
E Enter Press to confirm operation.
F Arrow Keys
Moving the cursor (Up, Down, Left, Right).
In the manual mode, press the Left or Right arrow to switch
among the lead groups.
Pressing Shift + Up/Down can turn pages on the Order
Manager screen and the File Manager screen.
G REVIEW
10s ECG data sampled before pressing the REVIEW key will
be printed out in the AUTO mode.
NOTE: The system will not respond to the REVIEW key
unless 10s data has been collected on the main screen.
H PRINT/STOP Press to start or stop printing reports
I 1mV/COPY
In the manual mode, pressing the 1mV/COPY key can insert a
1mV calibration mark in the printing course.
In the auto or rhythm mode, pressing the 1mV/COPY key can
print the ECG report which was printed out last time.
J RESET
Press to reset the baseline.
NOTE: A large polarization voltage may cause baseline
drift. On the main screen, pressing the RESET key can
decrease the polarization voltage and draw the baseline to
zero quickly.
K FEED Paper
When the main screen, the freezing screen, the File Manager
screen1/2 or the preview screen is displayed, if Paper Marker
is set to Yes , you can press the FEED key to advance the
recorder paper to the next black marker; if Paper Marker is set
to No, you can press the FEED key to advance the paper for
2.5cm. Press the FEED key again to stop advancing the paper.
