Edgetech 4205 User Manual

A-105
A.0 4205 KITS
This section contains labeled diagrams and Bills of Materials for spare and tool kits.
A.1 4205 MPMT Spare Kits
Images and BOMs are available on the following pages:
0020596
ASSY TOP KIT SPARES 4205 MP 100-400 KHZ TOW FISH
MTL
Part
Description
QTY
10 0018349
ASSY SUB BOARDSET CPU MBT10 E3825 MINI PASSIVE
HEATSINK ON GIGABIT USB 3.0 CARRIER
1
20 0006125
PCB ASSY POWER AMP ANALOG 4200 LIBERTY
ENGINEERING 200-0000040-1000
1
30
0021004
PCB ASSY TOP SIM2XA 4205 120-410 KHZ MP
1
40 0021101
PCB ASSY TOP SONAR ACQUISITION INTERFACE BOARD USB
AND DUAL LVDS INTERFACE SAIBU 4205
1
50
0020326
ASSY SUB CABLE 4205 CAP BANK LOCAL
1
60
0021054
PCB TOP ASSY POWER SUPPLY ANALOG DISTRIBUTION 4205
1
70
0020679
ASSY SUB CABLE 4205 SAIBU TO CPU USB
1
80 0017144
MEMORY FLASH GENERIC R-DRIVE IMAGE KONTRON E38XX
CPU
1
90
0020341
SOFTWARE EDGETECH FOLDER 4205 TOW FISH
1
100
0023061
PCB ASSY TOP INTERFACE MESTECH MODEM TDSL 1006
1
Table 7-7: 4205 MPMT 100-400 kHz Spare Kit
0021218
ASSY TOP KIT SPARES 4205 MP 230-850 KHZ TOW FISH
MTL
Part
Description
QTY
10 0018349
ASSY SUB BOARDSET CPU MBT10 E3825 MINI PASSIVE HEATSINK ON
GIGABIT USB 3.0 CARRIER
1
20 0006125
PCB ASSY POWER AMP ANALOG 4200LIBERTY ENGINEERING 200-
0000040-1000"
1
30
0021217
PCB ASSY TOP SIM2XA 4205 230-850 KHZ MP
1
40 0021101
PCB ASSY TOP SONAR ACQUISITION INTERFACE BOARD USB AND DUAL
LVDS INTERFACE SAIBU 4205
1
50
0020326
ASSY SUB CABLE 4205 CAP BANK LOCAL
1
60
0021054
PCB TOP ASSY POWER SUPPLY ANALOG DISTRIBUTION 4205
1
70
0020679
ASSY SUB CABLE 4205 SAIBU TO CPU USB
1
80
0017144
MEMORY FLASH GENERIC R-DRIVE IMAGE KONTRON E38XX CPU
1
90
0020341
SOFTWARE EDGETECH FOLDER 4205 TOW FISH
1
100
0023061
PCB ASSY TOP INTERFACE MESTECH MODEM TDSL1006
1
110
0006127
PCB ASSY TOP POWER AMP ANALOG 850 KHZ 4200 VHF
1
Table 7-8: 4205 MPMT 230-850 kHz Spare Kit
