USB Connectors
(6) USB connectors. Four on the back panel and two on the front. Located
on CPU.
Ethernet Connector
RJ-45 connector. It provides a 10/100BaseT Ethernet connection. Located
on CPU and 701-DL.
Video card
Video card with 4 Mini DP (Display)Connectors. Provides video display to
the monitor.
COM-1 NAV Connector
DB-9 female connector. RS-232 serial port that connects to the navigation
system. Located on CPU.
COM-3 Connector
DB-9 female connector. RS-232 serial port that can be used to connect to
the navigation system. Located on CPU.
Table 3-6: Starmux III Rack Mount Controls, Indicators and Connections
