Edgetech 4205 - Figure 7-1: Tailfin Removal; Figure 7-2: Aft Endcap Cable Disconnection

7-89
Figure 7-1: Tailfin Removal
3. Pull the tail from the vehicle carefully.
4. The aft endcap should now be exposed. Carefully disconnect all of the transducer cables from
their connectors.
Figure 7-2: Aft Endcap Cable Disconnection
