4-75
4.5 TCP/IP Address Settings
The 4205 high Definition Dual-frequency Side Scan Sonar System includes many Ethernet devices
connected on a common local area network (LAN). Each of these devices has a factory set TCP/IP address,
which under normal circumstances does not require changing.
Should any of these devices be replaced, or if upgrades are later installed, the TCP/IP addresses may need
to be reconfigured. Also, any computer that is to be connected to the 701-DL Digital Link must have its IP
address set to 192.9.0.nnn, where nnn is any integer from 1 to 100—except for the following reserved
addresses:
• 192.9.0.22 – Topside ADSL Modem
• 192.9.0.101 – Tow Vehicle CPU
• 192.9.0.102 – Topside Netburner (only used with 701-DL power PCB)
The factory IP address setting of the wired Ethernet connection for the laptop or 2U Rack Mount computer
included with the 701DL is 192.9.0.99,
For a list of the topside processor Ethernet devices and their TCP/IP addresses, refer to T
ABLE 4-2 (below)
and for the Towfish to T
ABLE 4-3 (below).
DEVICE
TCP/IP ADDRESS
ASDL Modem board 192.9.0.22
Table 4-2: Topside Processor Ethernet Devices TCP/IP Addresses
CPU board 192.9.0.101
Table 4-3: Towfish Ethernet Device IP Address
4.6 Connecting the System Components
All the system components, including optional components, such as a printer, navigation system, and
external sonar systems, connect to the topside processor. An example of a fully connected system is
shown in the connection diagram in F
IGURE 4-1.
WARNING! Do not connect the tow cable to the topside processor before
connecting it to the Towfish. Injury or death can occur if the exposed
connector on the tow cable is energized. Always connect the tow cable
to the Towfish first.
