2-31
I/O ports
(1) Ethernet
(1) Trigger
(1) Ethernet
(3) RS-232
(6) USB 2
(2) USB 3
(1) Trigger
Table 2-5: Starmux III Specifications Cable Specifications
The tow cables are used to both connect and tow the tow vehicle. Both cable types include a single
conductor and a shield. They also include an MCIL6F female wet-pluggable connector on the tow vehicle
end and either an MCIL4M male wet-pluggable connector on the topside processor end or an open
termination at this end for direct connection to the slip rings of a winch. A cable grip is included for
attaching the tow cable to the towing arm of the tow vehicle. Specifications for the 4205 tow cable
options, along with the power cables, are provided in the drawings that follow.
2.3.1 Kevlar Tow Cable Specifications
For more information on Kevlar Tow Cables, contact EDGETECH CUSTOMER SERVICE.
SPECIFICATION
VALUE
Construction
Polyurethane, Kevlar, PVC, Tinned Copper
Weight In Air
30 kg / 305 m (66 lbs / 1000 ft)
Weight in Seawater
7.8 kg / 305 m (17.3 lbs / 1000 ft)
Specific Gravity
1.45 g/cc
Strength Member:
Aramid Braid Minimum Break 1134 kg (2500 lbs)
Minimum Bend Radius (Dynamic)
25.4 cm (10.0 in)
Capacitance
30 pF/ft nominal
Impedance
50 Ω
Velocity of Propagation
66% nominal
Table 2-6: Kevlar Tow Cable Specifications
2.3.2 Armored Tow Cable Specifications
For more information on Armored Tow Cables, contact EDGETECH CUSTOMER SERVICE
SPECIFICATION
VALUE
Construction
Steel Armored
Grip Type
PMI (wet end)
Weight In Air
469 kg/km (315 lb/kft)
Weight in Seawater
397 kg/km (255 lb/kft)
Specific Gravity
5.4
Breaking Strength
71.2 kN (16,000 lbf)
Maximum Working Load
17.8 kN (4,000 lbf)
Minimum Bend Radius
23 cm (9 in.)
Voltage Rating
1,900 VDC
DC Resistance
9.8 Ω/km (9.8 Ω/kft)
6.9 Ω/km (6.9 Ω/kft)
Table 2-7: Armored Tow Cable Specifications
