Edgetech 4205 - Electronic Bottle and Connection Drawings; Figure 2-3: 4205 MPMT Towfish Endcap Connections

2-34
2.4.2 Electronic Bottle and Connection Drawings
Pressure Sensor
Port
TRANSDUCER
SS TX
-MP
PORT
TRANSDUCER
SS RX-MP
PORT
TRANSDUCER
SS RX-MP
STBD
TRANSDUCER
SS TX-MP
STBD
Pressure
Relief
Port
Figure 2-3: 4205 MPMT Towfish Endcap Connections
