Edgetech 4205 User Manual

A-106
4205 SIDE SCAN SYSTEM 0021769_REV_D
A.2 4205 Tri-Frequency Spare Kits
0021880 ASSY TOP KIT SPARES 4205 TRIFREQUENCY 120 410 850 KHZ TOW FISH
MTL
Part
Description
QTY
10
0018349
ASSY SUB BOARDSET CPU MBT10 E3825 MINI PASSIVE HEATSINK ON
GIGABIT USB 3.0 CARRIER
1
20
0021843
PCB ASSY TOP POWER AMP DUAL DIGITAL DDPA 120 KHZ RLJ1669
PASSIVE
1
30
0021844
PCB ASSY TOP SONAR INTERFACE MODULE II SIM2 4205 410KHZ -
850KHZ
1
40
0021101
PCB ASSY TOP SONAR ACQUISITION INTERFACE BOARD USB AND DUAL
LVDS INTERFACE SAIBU 4205
1
50
0022007
ASSY SUB CABLE 4205 TRIFREQUENCY CAPACITOR BANK TO DDPA
1
60
0021054
PCB TOP ASSY POWER SUPPLY ANALOG DISTRIBUTION 4205
1
70
0020679
ASSY SUB CABLE 4205 SAIBU TO CPU USB
1
80
0017144
MEMORY FLASH GENERIC R-DRIVE IMAGE KONTRON E38XX CPU
1
90
0022031
SOFTWARE EDGETECH FOLDER 4205 TOW FISH
1
100
0023061
PCB ASSY TOP INTERFACE MESTECH MODEM TDSL 1006
1
110
0012699
ASSY SUB 2205 STORAGE CAPACITOR 12 SIM 9840UF 63VDC
1
120
0012536
ASSY SUB 2205 STORAGE CAPACITOR 06 SIM 4920UF 63VDC
1
Table 7-10: 4205 Tri-Frequency 120/410/850 Spare Kit
0021881 ASSY TOP KIT SPARES 4205 TRIFREQUENCY 230 540 850 KHZ TOW FISH
MTL
Part
Description
QTY
10
0018349
ASSY SUB BOARDSET CPU MBT10 E3825 MINI PASSIVE HEATSINK ON
GIGABIT USB 3.0 CARRIER
1
0021509 ASSY TOP KIT SPARES 4205 MP 230-540 KHZ TOW FISH
MTL
Part
Description
QTY
10
0018349
ASSY SUB BOARDSET CPU MBT10 E3825 MINI PASSIVE HEATSINK ON
GIGABIT USB 3.0 CARRIER
1
20
0006125
PCB ASSY POWER AMP ANALOG 4200 LIBERTY ENGINEERING 200-
0000040-1000
1
30
0021005
PCB ASSY TOP SIM2XA 4205 230-540 KHZ MP
1
40
0021101
PCB ASSY TOP SONAR ACQUISITION INTERFACE BOARD USB AND DUAL
LVDS INTERFACE SAIBU 4205
1
50
0020326
ASSY SUB CABLE 4205 CAP BANK LOCAL
1
60
0021054
PCB TOP ASSY POWER SUPPLY ANALOG DISTRIBUTION 4205
1
70
0020679
ASSY SUB CABLE 4205 SAIBU TO CPU USB
1
80
0017144
MEMORY FLASH GENERIC R-DRIVE IMAGE KONTRON E38XX CPU
1
90
0020341
SOFTWARE EDGETECH FOLDER 4205 TOW FISH
1
100
0023061
PCB ASSY TOP INTERFACE MESTECH MODEM TDSL 1006
1
Table 7-9: 4205 MP 230-530 kHz Spare Kit
