Edgetech 4205 - Table 3-2: Starmux IV Rack Mount Controls, Indicators, and Connections

3-52
4205 SIDE SCAN SYSTEM 0021769_REV_D
Power Switch Rocker switch. Turns the 2U-CPU computer on or off.
USB Connectors (4) USB connectors
Ethernet Connector RJ-45 connector
Video card
Video card with 4 Mini DP (Display)Connectors. Provides video display to
the monitor.
COM-1 NAV Connector
DB-9 female connector. RS-232 serial port that connects to the navigation
system when the Starmux IV is not used.
COM-3 Connector DB-9 female connector. General-purpose RS-232 serial port.
Table 3-2: Starmux IV Rack Mount Controls, Indicators, and Connections
