Figure 3-4: Labeled Rear Picture of 2300 Rackmount
USB Connectors
Fuses
Telemetry/Subsea Serial Ports
Sea Cable Connector
Optional Trigger Connectors
Network Ethernet Ports
Grounding
Lug
Power
Switch
Power Switch
Network Ethernet Ports
Video Card
PC COM-1
PC COM-3
FSK Sync
Connector
NAV Input for Network Broadcast
1PPS Connector
