3.2.2 Starmux IV 4205 Rack Mount Controls, Indicators, and Connections
Starmux IV Power Switch
Rocker switch. Turns the Starmux Digital Link on or off. The rear line
power switch needs to be turned on for this switch to function.
LAN Indicator Light
Green indicator. Flashes continuously when an Ethernet connection is
established.
LINK Indicator Light
Green indicator. Flashes while the Starmux Digital Link is establishing a
reliable communications link with the side-scan sonar. Illuminates
continuously when a reliable communications link with the sonar is
Fish Power Indicator Light
Red indicator. Illuminated when the Starmux Digital Link is, and the
side-scan sonar is on.
Green indicator. Illuminated when the Starmux Digital Link is on.
Display the current Starmux system voltage
Connection for the AC power cord.
Line Power Switch
Rocker switch. Switches AC power to the POWER switch on the front
panel of the Starmux Digital Link.
AC fuse
Electrical grounding lug for sea ground.
Network Ethernet
Connectors (4)
RJ-45 Standard Ethernet connection for connecting to the external
topside processor.
Input data connector for a FSK beacon external trigger.
2.5A replaceable fuse
Sea Cable Connector
Sub Conn MCBH4F female connector to sea cable going out to tow
vehicle.
1 PPS Connector Pulse per second connector.
Trigger Connectors (2) Optional digital ports provided for triggers.
Serial Com Ports (6) Serial ports for external device connections.
USB Connectors (2) USB connectors.
DVD Drive DVD\RW drive.
BACK PANEL COMPUTER
CEE-type AC input connector.
