Edwards EXS Series User Manual

Descripon
Rang Units
For EXS450 <10 mA
†Typical earth leakage values were measured at steady-state condions.
Not
e that higher leakage currents may occur:
i) under transient condions such as power on or pump acceleraon.
ii) with the abnormal supply conguraons such as a missing or earthed phase or
unbalanced supply voltages.
iii) if EMC switch turns to on posion.
Contact us for more informaon about the conguraon requirements for earth leakage
reducon.
Recommended fuse type:
Fuse Class aR (IEC 60269), UL class T.
Table 9
Electrical connecons
Descripon
Mang connector descripon/external
supply rang
Internal supply
rang
Mains connecon Main terminals, suitable for 1.5 mm² -
25 mm², rated voltage 1000 V, rated cur-
rent 76 A
External run, stop and
emerg
ency stop but-
ton*
control terminals, suitable for 0.08 mm² -
2.5 mm², rated voltage 800 V, rated cur-
rent 24 A
Warning or shutdown
signal
Control terminals
1 x 7:1 and 1 x 7:2 are for GENERAL SHUT-
DOWN (250 V a.c. maximum 1 A, 30 V a.c.
maximum 1 A, minimum load 5 V d.c.
10 mA)
1 x 7:3 and 1 x 7:4 are for STATOR WARM
UP READY (48 V d.c. maximum 50 mA)
1 x 7:5 and 1 x 7:6 are for STATOR TEMP
HIGH WARNING (48 V d.c. maximum
50 mA)
* If there is no external connecon, a bridge must be ed to operate the pump.
Table 10
Wire assembly according to VDE 0295
Wire size (mm²) Fine stranded wires VDE 0295 class 5
6 84 x 0.30
10 80 x 0.40
16 128 x 0.40
25 200 x 0.40
35 280 x 0.40
50 400 x 0.40
07/2021 - ©Edwards Limited
Page 21A41870880_A
