Figure 13 Interspool connecons on the pump
1. Interspool 2. G 3/8 inch BSP port1. Interspool 2. G 3/8 inch BSP port
5.8 Electrical supply
WARNING:
Ensure tha
t the electrical installaon of the dry pumping system conforms to all local,
regional and naonal safety requirements. It must be connected to a suitably fused
and protected electrical supply and a suitable earth (ground) point.
WARNING:
The pump will res
tart automacally when the electrical supply is restored aer an
electrical supply failure. To prevent the automac restart, the pump must be
connected to the electrical supply through suitable control equipment which must be
reset manually aer an electrical supply failure.
WARNING:
Risk of electric shock. Isolat
e the electrical supply before disconnecng the electrical
supply cable from the dry pumping system.
