3.7.3 Keyboard and Mouse Connections
Connect Keyboard and Mouse as follows:
1. Pass Keyboard and Mouse cables through hole to Computer Compartment.
2. Connect Keyboard and Mouse cables to Computer.
Figure 3-18: Keyboard and Mouse
Connections
