EFI Pro 16h - Media Table Top Assembly

Document ID: OMM-00131 Rev. E
48
3.14.2 Media Table Top Assembly
Ensure all table top parts are in close proximity and assemble the table top in accordance with the illustration.
It is best to assemble the Table Top in the upside down position and then flip over and attach to the hinges located on the
table base.
1
2
3
4
Figure 3-46: Media Table Top Assembly
1 Hardware 2 Cross Brace 3 Table Top 4 Locking Device
