EFI Pro 16h - Page 31

Document ID: OMM-00131 Rev. E
31
1
2
3
4
5
6
9
8
7
Figure 3-25: Feed Roll Assembly Exploded View (Assembly)
1 Media Roll 2 Level (to Level Side Plates & Dancer) 3 Printer Mounting Bracket
4Motor Side Plate 5Media Chucks 6 Printer Mounting Bracket
7 Dancer Half-Moon Stop 8 Flat Side Plate 9 Dancer
