6. Temporarily mount the angle bracket to the side of the
inverter (located at the bottom, one on each side). Mark a
hole on the wall based on the hole location inside the
right-angle bracket. (Repeat this step for both sides)
7. Remove the angle bracket and drill a hole at
the marking. Use the drill bit size based on
the anchor type or screw size as directed in
step 3 (Repeat this step for both sides).
8. Attach the angle brackets (one on each side) to
the inverter and to the wall using the correct
hardware. Once the bracket is secure, the wall
installation is complete.
