Order removing 60mm flying knives:
1) Remove the wedge fixing bolts, Figure 8 - Pos. 2.
2) Tighten wedge-jacking screws, Figure 8 - Pos. 1.
3) Remove the wedge, Figure 8 - Pos. 5.
4) Remove the flying knife, Figure 8 - Pos. 3.
5) Clean the knife location slot.
6) Insert the new flying knife.
7) Insert the wedge.
8) Tighten the fixing bolts.
Figure 8
ELDAN Recycling A/S Page 31
