Order removing 25mm flying knives:
1) Remove the fixing bolts, Figure 9 - Pos. 3
2) Remove the flying knife, Figure 9 - Pos. 1
3) Clean the knife holder, Figure 9 - Pos. 2
4) Insert the new flying knife
5) Tighten the fixing bolts
Figure 9
Remove knife Bolts
ad 1 Care should be taken, when removing the bolts, to ensure that the locking
washers are also removed as a pair, Figure 7.
Remove the flying knife
ad 2 The knife is best removed from the t op of the Rasper. To keep the rotor in
balance and thus keep it easy to turn , the knives should be removed and
replaced with a new one in one operation.
Cleaning the knife holder
ad 3 Before attempting to refit the knife, it is essential that the location in the
holder, Figure 9 - Pos. 4, is scrupulously clean to ensure that the
knife sits firmly on the holder.
ELDAN Recycling A/S Page 32
