5
To replace the oven light 48
Solutions to common problems 49
Service failure mode definitions 51
Sample warranty 52
Section B - INSTALLATION INSTRUCTIONS 53
Safety 53
Definitions 53
Finding information 54
Preparing for installation 54
Gas supply requirements 54
Gas and electric requirements table 54
Electrical power supply requirements 55
Gas and electrical rough-in 55
Cabinet and countertop preparation 55
Cutout dimensions 57
E36DF76EPS and E48DF76EPS overall dimensions side view 58
E30DF74EPS overall dimensions side view 59
Installing the anti-tip bracket 60
Gas regulator and electrical conduit location 63
Installing optional backguards 64
Removing the oven door 65
Reinstalling the oven door 65
Making the electrical connections 66
Grounding instructions 66
Connecting to a four-wire electrical system 66
Connecting the green appliance wire to the neutral supply wire 66
Connecting the green appliance wire to a grounded
supply wire or a grounded cold water pipe 67
Making the gas connection 68
Installing the range 68
Installing the burner components 68
Operation 69
SECTION C - THEORY OF OPERATION 70
Gas flow 70
Top burner ignition and reignition system 73
Oven operation 74
Air movement in the oven during convection bake and convection roast 76
Cooling blower air movement 77
The self-cleaning cycle 78
SECTION D -TROUBLEINGSHOOTING 79
Index 79
Electrical components will not operate 80
Flame too large and yellow on top burner 80
Flame too small on top burner 80
Flame goes out, when valve is turned to the low position 80
Top burners, not burning properly 80
One top burner, not burning properly 81
Top burner valve difficult to turn 81
Igniters do not spark when the burner knob is turned to the lite position 81
Igniters spark but burner does not ignite 81
Igniters continue to spark after burner is ignited 81
Oven does not operate in any fuction 82
Oven temperature off more than 10° 83
Oven does not operate in bake 83
Oven does not operate in broil 84
Oven does not heat in convection bake and convection fan does not run 84
