03-2009 SOI/DT-mdm FCPD-dp Quality-fz 66/91 599 70 56-70
YES
NO
NO
YES
E82: Error in reading the RESET/OFF position of the programme
selector
E82
Reading of position “0” of the selector when the appliance is switched on, or configuration
error
E82
Tests to be performed:
Switch the appliance OFF
(selector position “0”).
Do any LEDs light?
Switch the appliance on and
turn the programme selector (in
the versions with knob),
push the programe buttons
(INPUT version)
to every position: wait at least
10 seconds before passing to
the next one.
Does alarm E82 reappear?
Replace the circuit board
and restart the diagnostic
cycle to check for further
alarms.
Replace the circuit board and
restart the diagnostic cycle to
check for further alarms.
Restart the diagnostic
cycle to check for
further alarms.
If there are traces of burning on the
circuit board, refer to page 90
To Next Page
