5.5 TABLE OF ALARMS
Alarm Possible fault Action/machine status Reset Alarm Pag.
E00
No alarm
---------------- ---------------- ---------------- ----------
E11
Difficulties in water fill for washing
Tap closed or water pressure too low; Drain tube improperly
positioned; Water fill solenoid valve is faulty; Leaks from water circuit
on pressure switch; Pressure switch faulty; Wiring faulty; PCB faulty.
Cycle is paused with door locked. START/RESET 21
E12
Difficulties in water fill for drying
Tap closed or water pressure too low; Drain tube improperly
positioned; Water fill solenoid valve is faulty; Leaks from water circuit
on pressure switch; Pressure switch faulty; Wiring faulty; PCB faulty.
Cycle is paused with door locked. START/RESET 23
E13
Water leakage
Drain hose incorrectly positioned; mains pressure insufficient; water
fill solenoid faulty; leakage/blockage of pressure switch hydraulic
circuit; pressure switch faulty.
Cycle is paused with door locked. START/RESET 24
E21
Difficulties in draining for washing
Drain tube kinked/clogged/improperly positioned; Drain filter
clogged/dirty; Drain pump faulty; Pressure switch faulty; Wiring faulty;
PCB faulty.
Cycle is paused (after 2 attempts). START/RESET 26
E22
Difficulties in draining for drying
Drain tube kinked/clogged/improperly positioned; Drain filter
clogged/dirty; Drain pump faulty; Pressure switch faulty; Wiring faulty;
PCB faulty.
Cycle is paused. START/RESET 28
E23
Drain pump triac faulty
Drain pump faulty; Wiring faulty; PCB faulty.
Safety drain cycle - Cycle stops with
door unlocked.
RESET 30
E24
Fault in “sensing” circuit of drain
pump triac (wrong input signal to
microprocessor)
PCB faulty.
Safety drain cycle - Cycle stops with
door unlocked.
RESET 31
E31
Electronic pressure switch circuit
faulty (frequency of pressure switch
signal out of limits)
Electronic pressure switch; Wiring; PCB faulty. Cycle blocked with door closed. RESET 31
E32
Incorrect calibration of electronic
pressure switch
(The electronic pressure switch
generates a signal with instable
frequency during the drain phase)
Drain tube kinked/clogged/improperly positioned; Drain filter
clogged/dirty; Drain pump faulty;
Leaks from water circuit on pressure switch; Pressure switch;
Wiring faulty; PCB faulty.
Cycle is paused. START/RESET 32
E35
Water overflow
Water fill solenoid faulty; Leaks from water circuit on pressure switch;
pressure switch faulty; wiring faulty; PCB faulty.
Cycle blocked. Safety drain cycle. Drain
pump always in operation (5 minutes
on, 5 minutes off etc.).
RESET 33
E38
Pressure chamber blocked
(water level does not vary for at least
30 sec. during drum rotation
Motor drive belt broken; Hydraulic circuit pressure switch clogged. Heating phase skipped.
ON/OFF
RESET
34
E3A
Heating elem. relay sensing faulty
(input signal to microprocessor
always 0V or 5V)
PCB faulty. Cycle blocked with door closed. RESET 35
E41
Door open (after 15 sec.)
Door interlock faulty; wiring faulty; PCB faulty. Cycle paused. START/RESET 36÷38
