03-2009 SOI/DT-mdm FCPD-dp Quality-fz 79/91 599 70 56-70
NO
YES
Tests to be performed:
ED4 ED4: Drying relays faulty ED4
WD
board
Replace the wiring and restart the
diagnostic cycle to check for
further alarms.
Measure across terminals J8-3, J8-
4 of the connector and the structure
of the appliance- see fig.6 -
Is there any leakage?
Replace the WD board and restart the
diagnostic cycle to check for further
alarms.
fig. 6
∞
If there are traces of burning on the
circuit board, refer to page 90
To Next Page
