10.1 Key to circuit diagram WD
Electrical components on appliance Components on main board
1. Analogue pressure switch
2. NTC temperature sensor
3. Solenoid valve for prewash
4. Solenoid valve for wash
5. Condensation solenoid valve
6. Thermal cut-out (circulation pump)
7. Pump circulation
8. Thermal cut-out (drain pump)
9. Drain pump
10. Stator (motor)
11. Rotor (motor)
12. Thermal cut-out (motor)
13. Tachometric generator (motor)
14. Interference filter
15. Instantaneous door interlock
16. Traditional door interlock
17. Heating element (with thermal fuses)
18. Motor with half field
19. Motor without half field
20. Circuit board
21. Flowmeter
22. LCD Module
23. Humidity temperature sensor
24. Drying temperature sensor
25. Motor fan
26. Drying heating elements
27. Manually reset thermostat
28. Automatically reset thermostat
29. WD board
DOOR_TY Door interlock Triac
DRAIN_TY Drain pump Triac
REC_TY Triac circulation pump
K1 Heating element relay
K2 Motor relay: clockwise rotation
K3 Motor relay: anti-clockwise rotation
K4 Motor relay: half field power supply (some models)
MOTOR_TY Motor Triac
ON/OFF Main switch (programme selector)
PWELW_TY Pre-wash solenoid Triac
WELV_TY Wash solenoid Triac
BEL_TY Beach solenoid Triac
