03-2009 SOI/DT-mdm FCPD-dp Quality-fz 16/91 599 70 56-70
Alarm Possible fault Action/machine status Reset Alarm Pag.
E42
Problems of door closure
Door interlock faulty; wiring faulty; PCB faulty. Cycle paused. START/RESET 40÷42
E43
Interlock power supply triac faulty
Door interlock faulty; wiring faulty; PCB faulty. (Safety drain cycle) Cycle blocked. ON/OFF RESET 44÷45
E44
Door interlock sensing circuit triac
faulty
PCB faulty. (Safety drain cycle) Cycle blocked. ON/OFF RESET 46
E45
Door interlock sensing circuit triac
faulty (wrong input signal to
microprocessor)
PCB faulty. (Safety drain cycle) Cycle blocked. ON/OFF RESET 46
E51
Motor power supply triac short-
circuited
PCB faulty; current leakage from motor or from wiring.
Cycle blocked, door locked (after 5
attempts).
RESET 47
E52
No signal from motor tachometric
generator
Motor faulty; wiring faulty; PCB faulty.
Cycle blocked, door locked (after 5
attempts).
RESET 48÷50
E53
Motor triac sensing circuit faulty
(input signal to microprocessor
wrong)
PCB faulty. Cycle blocked, door locked. RESET 52
E54
Motor relay contacts sticking (high
voltage level when the relay changes
to OFF)
PCB faulty; current leakage from motor or from wiring.
Cycle blocked, door locked (after 5
attempts).
RESET 53
E61
Insufficient heating during washing
NTC sensor faulty; heating element faulty; wiring faulty; PCB faulty. The heating phase is skipped. START/RESET 54
E62
Overheating during washing
(temperature higher than 88°C for a
time higher than 5 min.)
NTC sensor faulty; heating element faulty; wiring faulty; PCB faulty.
Safety drain cycle – Cycle stopped with
door open.
RESET 55÷56
E66
Heating element power relay faulty
(incongruence between sensing and
relay)
PCB faulty.
Safety drain cycle – Cycle stopped with
door open.
RESET 57÷58
E68
Current dispersion to earth (value of
mains voltage different from main
value)
Current dispersion between between heating element and earth. Cycle blocked with door open. RESET 59÷60
E69
Heating element interrupted
Wiring faulty; Heating element for washing interrupted (thermofuse
open).
---------------- START/RESET
61÷62
E71
Washing NTC sensor faulty (short-
circuited or open)
Wiring faulty; Washing NTC sensor faulty; PCB faulty. The heating phase is skipped. START/RESET 63
E72
Drying condenser NTC sensor faulty
(voltage value out of limits, sensor
short-circuited or open)
Wiring faulty; Drying NTC sensor (condenser) badly positioned or
faulty; WD board faulty.
The drying heating phase is skipped. START/RESET 64
E73
Drying duct NTC sensor faulty
(voltage value out of limits, sensor
short-circuited or open)
Wiring faulty; Drying NTC sensor (duct) badly positioned or faulty;
WD board faulty.
The drying heating phase is skipped. START/RESET 65
E74
Washing NTC sensor badly
positioned
Wiring faulty; Washing NTC sensor badly positioned; NTC sensor
faulty; PCB faulty.
The heating phase is skipped. START/RESET 66
E82
Error in selector reset position
PCB faulty (Wrong configuration data). ---------------- RESET 67
E83
Error in selector reading
PCB faulty (Wrong configuration data. Cycle cancelled. START/RESET 68
