Electrolux EWM2100 - Page 77

03-2009 SOI/DT-mdm FCPD-dp Quality-fz 77/91 599 70 56-70
ED2
WD
board
Fig. 21
Fig. 22
Condenser
Fig. 23
Push the red button to reset
the thermostat.
Fig. 24
Belt well tense and inserted correctly
inside the pulleys.
If there are traces of burning
on the circuit board, refer to
page 90
