29
9500
(B)
(A)
3mm
Adjusting Needle Threader Switch
Adjust the upper switch position as follows if the instructional display will not disappear.
1. Remove screws (A) ( 2 pieces) and remove
the motor cover .
2. Loosen screw (B) and adjust the position of switch
position by moving it up or down, so that the needle
threader stops with a 3 mm gap between the slider
and the top end of the guide slot.
3. Attach the motor cover with Screws (A).
q
q
e
r
w
(A)
w
r
e
