6
9500
(A)
(B)
(C)
(D)
Changing External Parts (6)
1 Remove the face cover, top cover and belt cover.
2 Loosen Screws (A), (B), (C) and remove Screw (D)
and remove the rear cover.
Note: Lower the presser foot.
To attach:
3Follow the above procedure in reverse.
Rear cover
To remove:
To Next Page
