ELTRA CS-800 User Manual

13
2.2 9BFrom S/N 0767xxxxxx to 0950xxxxxx
The CS-800 is equipped with a flow sensor employing a pressure transducer, and
with the corresponding boards HF-41 and later the HF-42.
These boards also offer:
• Current limit for the induction furnace (on board HF 41/42 adjustment)
• Oxygen flow only during combustion (on board jumper)
• Gas saving mode by controlling the oxygen flow (start / stop) by the software
This function has been included later in the software, from SN / 1080xxxx
Analyzers from SN / 0767 to SN / 1079 can be upgraded with this function.
For description see corresponding service manual.
Fig. 5: Draft 2-01-1-1 (pressure transducer)
