ELTRA CS-800 User Manual

53
Fig. 28: Draft 1-21-1
Pos: 5.29 /0 020 Über sc hrif ten /ELT RA 1.1 Über sc hri ften /11 I R-c ell t e mper atur e c ontr ol i s ou t o f r ange ELTR A @ 6\ mod_1368687694553_9.docx @ 40448 @ 2222 @ 1
3.13 26BIR-cell temperature control is out of range
Pos: 5.30 /0 010 ELTR A/ 0015 s ervic e_i nstr uc tio ns/C S-800 _S ervic e/ 001 5 F ehler /01 75 M od ul IR -C ell Temp eratur Kontr olle EL TRA @ 6\mod_1377688607482_9.docx @ 46663 @ 32 @ 1
If in the device state the graphs of IR-temperature °C or %IR-power are not in the
green area, adjust the temperature. See chapter IR-cell temperature control.
Device state
IR Temperature
IR °C
IR %Power
Pos: 5.31 /0 020 Über sc hrif ten /ELT RA 1.1 Über sc hri ften /11 Bre ak er t urns off at the begi nni ng o f c omb usti on E LTR A @ 6\mod_1368688648887_9.docx @ 40470 @ 3222334443 @ 1
3.14 27BBreaker turns off at the beginning of combustion
Pos: 5.32 /0 010 ELTR A/ 0015 s ervic e_i nstr uc tio ns/C S-800 _S ervic e/ 001 5 F ehler /01 80 M od ul Br a ker t urns of f at ST ART ELTR A @ 6\ mod_1377688607745_9.docx @ 46675 @ 23 @ 1
If the circuit breaker turns off at the beginning of combustion then:
– Unplug the analyzer mains power plug.
– Switch on the breaker.
DANGER
Mortal danger from electric shock
Exposed power contacts - High Voltage
