3.17 30BNo or low oxygen pressure
Pos: 5.38 /0 010 ELTR A/ 0015 s ervic e_i nstr uc tio ns/C S-800 _S ervic e/ 001 5 F ehler /01 95 M od ul N o or lo w o xygen pr ess ure ELT RA @ 6\mod_1377688609900_9.docx @ 46711 @ 23334443 @ 1
After pressing the START button, the following message appears:
"no oxygen pressure"
3.17.1
93BPossible faults on the front panel of the analyzer
Fig. 34: Front side panel
– Is the power switch (1) set on position 2?
– The pressure on the oxygen gauge (2) may be too low. 1.5bar is normal
(22psi). The pressure remains constant when the furnace is closed, and it
sinks during the upward movement of the furnace floor.
– Check the oxygen pressure in the supply line or tank. 4 to 6 bar (60 to 90psi)
showing on the pressure gauge is normal.
5
1
4
3
