How to use
66
To select layout:
1. Open drop down list in in layout section of Main window.
2. Select layout. It will be loaded and all child windows will get arranged accordingly.
Delete layout
It is easy to create many layouts and it is also easy to delete them.
To delete layout:
1. Load layout first.
2. Press button to delete layout in the Main window.
Technical info
Layouts are saved in Settings\*.lay files.
Pos: 9.4.30 /00 25 Überschriften /ELTRA 1.1 Übersc hriften/11 M otor @ 7\mo d_138539090 5702_9.docx @ 52 821 @ 2 @ 1
7.15 Motor
Pos: 9.4.31 /00 10 ELTRA/0005 so ftware_help/Tga /How to use/M otor @ 7\ mod_1385390858 705_9.docx @ 52810 @ @ 1
Motor is rotating crucibles and lids carousels. Actual carousel positioning can be observed in
the Crucibles window.
Rotate manualy
Motor is considered rotating (or busy) after command to rotate, until specified crucible position is
reached. This, however, doesn’t necessary means that there will be an actual rotation.
To rotate motor:
1. Login as Administrator.
2. Mark Pause in the Flow window.
3. Mark Move option in the Motor window.
4. Select crucible position and click Go button
5. Wait until motor finish rotation.
Motor rotation can only occur if Furnace closed input is set.
Motor stuck block is a special feature to prevent possible damage to the instrument. If motor
moving sensor doesn’t change for a certain number of steps, then motor rotation will be
blocked. Instead of actual rotation, a high-pitch beeper made sound can be heard. This
condition can be only reset by removing power from the instrument.
Too high or too low Error value could indicate a mechanical or electrical/electronic problem.
Calibrate
Motor home position calibration is necessary to ensure accurate crucible positioning on the
balance pedestal.
To calibrate motor home position:
1. Login as Administrator.
2. Mark Pause in the Flow window.
