How to use
48
Receiving STAT for too long
Prompt to put calibration weight
Calibration is in progress
Pos: 9.4.6 /002 5 Überschriften/ELTR A 1.1 Übersc hriften/11 Co mmunications @ 7\mod_138 4179223550_9. docx @ 52221 @ 2 @ 1
7.3 Communications
Pos: 9.4.7 /001 0 ELTRA/0005 s oftware_help/Tg a/How to us e/Communicatio ns @ 7\mod_ 1384179187608 _9.docx @ 5221 0 @ @ 1
Communications can be monitored in the Controller window, Motor related – in the
Motor window, Balance related – in the Balance window, Heater related – in the Heater window.
Status window adds to it, representing status in the compact view.
Digital inputs and outputs
Digital inputs represent sensors and all sort of digital detectors. Digital outputs control valves or
switch on/off certain electronics.
Cooling fan output is protected. It can only be set if Furnace closed input is set.
Open furnace output is protected. It can only be reset if Cooling fan output is reset.
Disconnect
Upon disconnection detection, if there are no communications from PC for 5 seconds, following
will occurs in the device:
• Heater power off.
• Oxygen and nitrogen off.
• Motor stop and reset.
• Counter reset to 0.
Pos: 9.4.8 /002 5 Überschriften/ELTR A 1.1 Übersc hriften/11 Co m-ports @ 7\m od_13854528 63675_9.docx @ 52880 @ 2 @ 1
7.4 Com-ports
Pos: 9.4.9 /001 0 ELTRA/0005 s oftware_help/Tg a/How to use/C om-ports @ 7\mod_13854 52798397_9.doc x @ 52869 @ @ 1
Controller and Balance both are required com-ports to operate. Therefore minimum 2 com-ports
should be present in the PC.
Assigning com-ports
Assigning proper com-ports is not an easy task, but it has to be carried once, before the
instrument can run.
• Device is connected with the PC, main switch in position 1
Firstly you have to identify which COM-Port or USB-Port (TGA-PCB V3.x) is connected at
your PC.
Go to device manager (1) and browse for the available COM & LTP ports.
