Embedded Systems LogiMachine5 Power User Manual

119
 PIN code  specify PIN code to access the plan
 Primary background image  choose primary background image from the list added
in Vis.graphics  Images/Backgrounds
 Secondary background image  choose secondary background image from the list
added in Vis.graphics  Images/Backgrounds
 Background color  choose background color of the plan
 Touch background color – define a color for touch visualization
 Repeat background image  either to show the image once or repeat it and fill the
whole plan
 Fixed primary background  specify if first background image should be fixed. By
enabling this, you can enable Parallax effect for your visualization
 Admin only access  enable admin only access for this floor
When clicking on Background image, the following window appears with background images
which has to be added in Vis.graphics  Images/Backgroundsin advance:
You can duplicate the plan with all its objects and settings by pressing on icon.
Levels can be sorted by pressing and icons. You can export the plan structure by clicking
in this icon
6.7.2. Layouts / Widgets
Layouts are used as templates for further use when adding Levels in Levels/Plans tab.
