6. LogicMachine configuration
Login
Password
admin
admin
This is a home directory for LogicMachine configuration management. The main menu consists
of the following menus:
 Scripting  scripting repository management
 Objects KNX bus object management
 Object logs KNX bus object historical logs
 Schedulers administrator interface for user mode schedulers
 Trend logs  administrator interface for trend logs
 Scenes  scene visual editor
 Vis.structure  visualization structure definition
 Visualization Visualization creation, control and monitoring
 Vis.graphics icon, background, font management
 Utilities  utilities including import from ETS, reset object DB, backup, update system
installation
 User access  user access level definition
 BACnet – BACnet client with scanner
 Power meter – voltage, current, power value mapping to KNX objects
 DALI  DALI master (over RS485 gateway)
 Modbus  Modbus mapper
 BLE  Bluetooth device mapping (over USB gateway)
 Alerts  alert messages defined with alert function
 Logs  log messages defined with log function
 Error log  error messages in KNX bus
 Help  documentation for scripting syntaxes
