3. Quick startup guide

3.1. Connection

 Mount the device on DIN rail

 Connect the KNX bus cable

 Connect 24V power supply to the device (red pole to 24V+, grey pole to GND)

 Connect Ethernet cable coming from the PC

3.2. Default login parameters

admin

Password

admin

IP address

192.168.0.10

Network mask

255.255.255.0

The device can be accessed by opening web browser (Chrome, Firefox, Safari are supported)

and entering IP of the device HTTP://IP

Secure access to the device is available via HTTPS://IP:Port

Supported web browsers: Google Chrome or Mozilla Firefox (for OS Windows), Safari (for OS X)

3.3. Factory default

You can either reboot the device by pressing RESET button or reset the configuration to factory

defaults:

 Press and hold for <10 sec  reboot the device

 Press and hold for >10 sec  reset networking with IP to factory default

 Press and hold for >10 sec and again press and hold for >10 sec  full reset of

configuration to factory defaults

For more info please see here: http://openrb.com/discover-ip-of-logic-machine-or-streaming-

player/
