Chapter 6 Parameter Descriptions 47
F005 Low-speed operation setting
Range: 0.00~50.00Hz
【
3.00
】
F005 is to set the speed of low speed operation including the auto-testing at
start-up, and the operation when the low speed running command is
effective.
Note
Auto-testing at start-up: If the drive is set in elevator-door control mode, when it is
powered on, it will conduct low-speed CD at first. If it is interrupted during closing
the door, it will open it again, and close it after the door is opened completely. After
that, the drive stops and the auto-testing is over.
F006 CD or OD time limit
Range: 0.1~3600s
【
300.0
】
F006 is used to set the maximum time of CD and OD operation. You should
set it properly according to the actual conditions. The settings must be bigger
or equal to the sum of all the settings of CD or OD (parameter group of CD
and OD curve), otherwise error may occur (E028). Setting F006 correctly can
protect the system against abnormal operation of elevator door. The normal
operation time will not exceed F006, but when the CD or OD position limit is
invalid, which may cause the door cannot be opened or closed to the position,
the operation time may exceed F006, CD or OD error (E030) will be
activated.
Note
1) OD time: The duration from the drive receiving OD command until the door is
opened completely.
2) CD time: The duration from the drive receiving CD command until the door is
closed completely.
3) When the drive operates as a general-purpose drive, this parameter is invalid.
F007 Delay time for OD terminal command
Range: 0~3600.0s
【
0.0s
】
F007 is to set the time interval from the OD command becoming invalid to the
end of holding time of complete OD state. If the holding time is equal or
greater than F007, the drive will stop. If the door is not opened to the position
completely and OD command is cancelled at that time, the drive will stop
immediately and the delay function is invalid.
TD3200 Variable Speed Drive for Elevator Door Control User Manual
