Chapter 6 Parameter Descriptions 59
In single-phase PG mode, if the location in stopping status is not changed,
when the drive runs again, it will control the door to OD or CD according to
the curve shown in Figure 6-9 and Figure 6-10. If the location in stopping
status is changed and the changing exceeds 12.5% of the door width, when
the drive runs again, it will control the door to CD or OD completely according
to the setting of F005. After that, the drive will operate according to the curve
shown in Figure 6-9 and Figure 6-10.
F043 Display selection for F043~F066
Range: 0, 1
【
0
】
F043 decides whether to display F044~F066.
0: Not display
1: Display
F044 Number of pulse per revolution
Range: 1~9999
【
128
】
F045 PG phase
Range: 0, 1
【
0
】
F046 Direction of PG
Range: 0, 1
【
0
】
TD3200 drive adopts vector control mode. Relevant parameters of PG must
be set if close loop vector control mode is adopted.
In distance control mode, relevant parameters of PG should also be set
correctly so as to ensure the control effects.
TD3200 can use both two-phase PG and single-phase PG.
Note
1) Two phase PG signals are input via terminal X1 and X2, while single phase PG
signal must be input via X1.
2) TD3200 drive only provides 24V power supply, so please use 24V PG.
3) Use the PG with open collector output or push-pull output.
F047 Speed during door width auto-learning
Range: 0.00~50.00Hz
【
5.00
】
F047 defines the operating frequency in door width auto-learning process.
In order to reduce the door width error, F047 must not be too big so as to
avoid the shock when the door is in complete OD or CD status.
TD3200 Variable Speed Drive for Elevator Door Control User Manual
