60 Chapter 6 Parameter Descriptions
Note
Before the auto-learning, if speed control 1 (F001=0) is selected, the auto-learning
can be successful only if location limiting signal is input. If speed control 1 (F001≠0)
is not selected, the auto-learning can be done without location limiting signal.
F048 Selection of door-width auto-learning
Range: 0, 1
【
0
】
0: disabled
1: enabled
Set F048 to 1, press RUN, and the drive will begin door-width auto-learning
automatically.
After the auto-learning, setting of F048 will resume to 0 automatically.
Process of door-width auto-learning: After auto-learning is started, the door
will be closed, opened and then close. After the door is completely closed, the
door width information will be saved automatically.
Note
1) Relevant parameters of PG must be input correctly before the auto-learning.
2) Auto-learning is active in manual testing mode (F002=2) only,
3) During auto-learning process, the rail on which the door slide on must be free from
obstructions.
4) If two-phase PG is used, the door width information can be obtained manually
without starting the motor. Set F054 as 9999. First, record the pulse number P1 when
the door is complete closed, and then pull the door open completely, record the pulse
number P2 at this time. The P1 and P2 can be displayed as stopping parameters, refer
to F110 and F111.
Door width=|P2 - P1|. Input the results in F053 and F054 manually.
F049 OD speed changing location under
distance control
Range: 60.0%~90.0%(door width)
【
70.0%
】
In the OD process under distance control, the pulse number is recorded in
real time. When the pulse number is bigger or equal to the product of F049
and the door width, the elevator door will enter the OD ending phase and
operating at low speed.
F050 CD speed changing location under
distance control
Range: 60.0%~90.0%(door width)
【
70.0%
】
TD3200 Variable Speed Drive for Elevator Door Control User Manual
