G3 Series EtherCAT
TM
Technical Manual
4-22
TDG3ECM1-5EN 07/2020
Subject to change without notice
www.asco.com/g3
The combined draw of the +24VDC Valves and Outputs and +24VDC Node and
Inputs pins cannot exceed 8 Amps, at any given moment in time.
The Node and Inputs pin supplies power to the node electronics. This pin must be
powered at all times for communication node to be functional.
Class 2 Device Wiring Only Do Not Reclassify and Install as Class 1, 3 or Power
and Lighting Wiring
Wire connections shall be rated suitable for the wire size (lead and building wiring)
employed
Up to a maximum 16 I/O modules (units) can be connected to 1 Communication
Module not including any Sub-Bus and Miscellaneous modules, or equivalent
CLASS 2 WIRING: All field wiring shall be suitable for Class 1, Electric Light and
Power, or Class 2, 3 wirings are routed separately and secured to maintain
separation between 1) Class 2 wiring and all other class wiring, and 2) Limited
energy circuit conductors from unlimited energy circuit conductors
MULTIPLE CLASS 2 POWER SOURCES: When interconnects, class 2 sources shall
be Listed and rated suitable for parallel interconnection
Sources shall be Listed and rated suitable for parallel interconnection
CAUTION
