Emerson Aventics G3 Series User Manual

G3 Series EtherCAT
TM
Technical Manual
9-83
TDG3ECM1-5EN 07/2020
Subject to change without notice
www.asco.com/g3
Used to control a distributed valve manifold through the Sub
-Bus.
Module
Part No.
I/O Type
Short Circuit Protection
Status Bit Data Output Points
P580AEDS4010A00
NPN (Sinking) YES – Visual
YES (128) –
Optional
128
Diagnostics
BYTE Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
X
(Selectable)
Coil 7
Status
Coil 6
Status
Coil 5
Status
Coil 4
Status
Coil 3
Status
Coil 2
Status
Coil 1
Status
Coil 0
Status
X+1
Coil 15
Status
Coil 14
Status
Coil 13
Status
Coil 12
Status
Coil 11
Status
Coil 10
Status
Coil 9
Status
Coil 8
Status
X+2
Coil 23
Status
Coil 22
Status
Coil 21
Status
Coil 20
Status
Coil 19
Status
Coil 18
Status
Coil 17
Status
Coil 16
Status
X+3
Coil 31
Status
Coil 30
Status
Coil 29
Status
Coil 28
Status
Coil 27
Status
Coil 26
Status
Coil 25
Status
Coil 24
Status
X+4
Coil 39
Status
Coil 38
Status
Coil 37
Status
Coil 36
Status
Coil 35
Status
Coil 34
Status
Coil 33
Status
Coil 32
Status
X+5
Coil 47
Status
Coil 46
Status
Coil 45
Status
Coil 44
Status
Coil 43
Status
Coil 42
Status
Coil 41
Status
Coil 40
Status
X+6
Coil 55
Status
Coil 54
Status
Coil 53
Status
Coil 52
Status
Coil 51
Status
Coil 50
Status
Coil 49
Status
Coil 48
Status
X+7
Coil 63
Status
Coil 62
Status
Coil 61
Status
Coil 60
Status
Coil 59
Status
Coil 58
Status
Coil 57
Status
Coil 56
Status
X+14
Coil 127
Status
Coil 126
Status
Coil 125
Status
Coil 124
Status
Coil 123
Status
Coil 122
Status
Coil 121
Status
Coil 120
Status
32 additional coil status bits per each additional 32+ manifold driver board
128 coil status bits possible
