E300 Design Guide 23
Issue Number: 1
2.10.3 Compact external EMC filters
The external Compact EMC filter for size 3, 4 and 5, drives can be bookcase mounted, the details for each of the Compact EMC filters is provided
following.
Table 2-14 External Compact EMC filter data
N
When using the external Compact EMC filters an additional AC input line reactor is required which is selected to meet the requirements of EN 12015.
2.11 AC input line reactors
The AC power supply current harmonics for the complete Elevator system will be the vector sums of the harmonic currents for all of the individual
electrical loads in the system. Usually the main drive will dominate the electrical load, and it will be sufficient to ensure that these meet the harmonic
requirements detailed in IEC 61000-3-12 (EN 12015). Where drives are also used for ancillary functions such as door opening, ventilation etc., it may
be necessary to ensure that their harmonic contributions are not excessive, although generally their power ratings will be too small to be significant.
AC input line reactors must be provided in order to maintain the harmonics below the required levels detailed in IEC 61000-3-12 (EN 12015), the
following table provides details of suitable AC input line reactors to meet this standard whilst operating at rated power. Note the correct value reactor
depends upon the maximum input power for the particular Elevator system, and not necessarily the drive model / rating. For a given application, it is
important the actual maximum input power is measured / estimated and the correct reactor value calculated in inverse proportion to the power.
Table 2-15 AC input line reactors
Model CT part number
Weight
kg lb
400 V
03400025 to 03400100
4200-6126 0.4 0.88
4200-6219 0.6 1.32
04400150 to 04400172 4200-6220 0.7 1.54
05400270 to 05400300 4200-6221-01 1.7 3.75
Drive model
AC Input Line reactor
Inductance
mH
Current rating
A
Input power
kW
03200050 6 3.8 0.75
03200066 5 5.0 1.1
03200080 3 6.2 1.5
03200106 3 8.1 2.2
04200137 2.0 10.4 3.0
04200185 1.5 14 4.0
05200250 0.75 19.7 5.5
06200330 0.40 26.5 7.5
06200440 0.40 34.5 11.0
07200610 0.19 47.76 15.0
07200750 0.178 57.97 18.5
07200830 0.089 64.68 22.0
03400025 18 1.8 0.75
03400031 15 2.2 1.1
03400045 11 3.2 1.5
03400062 8 5.1 2.2
03400078 5 6.7 3.0
03400100 4 8.8 4.0
04400150 2.0 12.6 5.5
04400172 2.0 14.4 7.5
05400270 1.5 22 11.0
05400300 1.5 24.4 15.0
06400350 0.80 29.0 15.0
06400420 0.80 34.5 18.5
06400470 0.80 38.4 22.0
07400660 0.315 55.79 30.0
07400770 0.190 65.23 37.0
07401000 0.190 83.33 45.0
