Safety
information
Product
information
Mechanical
installation
Electrical
installation
Getting
started
User Menu A Commissioning
Advanced
Parameters
Diagnostics Optimization CT MODBUS RTU Technical Data
26 E300 Design Guide
Issue Number: 1
Table 2-26 Size 6 emission compliance (575 V drives)
Table 2-27 Size 7 emission compliance (200 V drives)
Table 2-28 Size 7 emission compliance (400 V drives)
Table 2-29 Size 7 emission compliance (575 V and 690 V drives)
Key (shown in decreasing order of permitted emission level):
E2R EN 61800-3:2004 second environment, restricted distribution
(Additional measures may be required to prevent interference)
E2U EN 61800-3:2004 second environment, unrestricted distribution
I Industrial generic standard EN 61000-6-4:2007
EN 61800-3:2004 first environment restricted distribution (The
following caution is required by EN 61800-3:2004)
R Residential generic standard EN 61000-6-3:2007
EN 61800-3:2004 first environment unrestricted distribution
EN 61800-3:2004 defines the following:
• The first environment is one that includes residential premises. It
also includes establishments directly connected without intermediate
transformers to a low-voltage power supply network which supplies
buildings used for residential purposes.
• The second environment is one that includes all establishments
other than those directly connected to a low-voltage power supply
network which supplies buildings used for residential purposes.
• Restricted distribution is defined as a mode of sales distribution in
which the manufacturer restricts the supply of equipment to
suppliers, customers or users who separately or jointly have
technical competence in the EMC requirements of the application of
drives.
IEC 61800-3:2004 and EN 61800-3:2004
The 2004 revision of the standard uses different terminology to align the requirements of the standard better with the EC EMC Directive.
Power drive systems are categorized C1 to C4:
Note that category 4 is more restrictive than E2R, since the rated current of the PDS must exceed 400 A or the supply voltage exceed 1000 V, for the
complete PDS.
2.13 EMC compliance (elevator standards)
This section provides specific information for the E300 drives when used in lifts, elevators and escalators which are required to comply with the
harmonized European EMC standards EN 12015 (emission) and EN 12016 (immunity). These standards were revised in 2004, although in some EU
countries the revised versions did not become available until 2006. The revised versions became mandatory in June 2006. They contain some
important changes from the previous (1998) versions. The information given here includes the requirements of the revised versions. For full details
refer to the EMC data sheet, which can be obtained from the supplier of the drive.
Motor cable
length (m)
Switching Frequency (kHz)
234681216
Using internal filter:
-C4
Using internal filter and ferrite ring (2 turns):
0 – 4 C3 C4
0 – 2 C3 C4
Using external filter:
0 – 20 R (C1) R (C1) I (C2) I (C2) I (C2) I (C2) I (C2)
20 – 100 I (C2) I (C2) C3 C3 C3 C3 C3
Motor
cable
length (m)
Switching frequency (kHz)
2346812
Using the internal filter
2~10
C4
Using the external filter (CT No. 4200-1132)
0 – 20 R (C1) R (C1) R (C1) R (C1) R (C1) R (C1)
20 – 40 R (C1) R (C1) R (C1) R (C1) R (C1) R (C1)
40 – 100 R (C1) R (C1) R (C1) R (C1) I (C2) I (C2)
Motor
cable
length (m)
Switching frequency (kHz)
234681216
Using the internal filter
2~10 C4
Using the external filter (CT No. 4200-1132)
0 – 20 R (C1)
R
(C1)
I (C2) I (C2) I (C2) I (C2) I (C2)
20 – 50 I (C2) I (C2) I (C2) I (C2) I (C2) I (C2) I (C2)
50 – 100 I (C2) I (C2) I (C2) - - - -
Motor
cable
length (m)
Switching frequency (kHz)
234681216
Using the internal filter
2~10
Using the external filter (CT No. 4200-0672)
0 – 20 R (C1) I (C2) I (C2) I (C2) I (C2) I (C2) I (C2)
20 – 50 R (C1) I (C2) I (C2) I (C2) I (C2) I (C2) I (C2)
50 – 100 I (C2) I (C2) - - - -
This is a product of the restricted distribution class according
to IEC 61800-3. In a residential environment this product may
cause radio interference in which case the user may be
required to take adequate measures.
Category Definition Corresponding code used above
C1 Intended for use in the first or second environments R
C2
Not a plug-in or movable device, and intended for use in the first environment only when
installed by a professional, or in the second environment
I
C3 Intended for use in the second environment, not the first environment E2U
C4
Rated at over 1000 V or over 400 A , intended for use in complex systems in the second
environment
E2R
