2.9 Items supplied with the drive
The drive is supplied with a copy of the safety information booklet, the Certificate of Quality and an accessory kit box including the items shown in
Table 2-11 below.
Table 2-11 Parts supplied with the drive (size 3 to 7)
Description Size 3 Size 4 Size 5 Size 6 Size 7
Control connectors
x 1 x 1
Relay connector
x 1
24 V power supply
connector
x 1
Grounding bracket
x 1
Surface mounting
brackets
x 2 x 2 x 2 x 2 x 2
Grounding clamp
x 1 x 1 x 1
DC terminal cover
grommets
x 2
Terminal nuts
M6 x 11
Supply and motor
connector
x 1 x 1 x 1
Finger guard
grommets
x 3 x 2
