E300 Design Guide 407
Issue Number: 1
8.12 Menu M: Comms
Serial Address (M01) defines the node address for the serial comms interface in the range from 1 to 247.
Changing the parameters does not immediately change the serial communications settings. See Reset Serial Communications (M06) for more
details.
Parameter
Range Default
Type
Open-Loop RFC-A RFC-S Open-Loop RFC-A RFC-S
M01 Serial Address 1 to 247 1 RW Num US
M02 Serial Mode
8 2 NP (0), 8 1 NP (1), 8 1 EP (2), 8 1 OP (3),
8 2 NP M (4), 8 1 NP M (5), 8 1 EP M (6),
8 1 OP M (7), 7 2 NP (8), 7 1 NP (9),
7 1 EP (10), 7 1 OP (11), 7 2 NP M (12),
7 1 NP M (13), 7 1 EP M (14), 7 1 OP M (15)
8 2 NP (0) RW Txt US
M03 Serial Baud Rate
300 (0), 600 (1), 1200 (2), 2400 (3), 4800 (4),
9600 (5), 19200 (6), 38400 (7), 57600 (8),
76800 (9), 115200 (10)
19200 (6) RW Txt US
M04 Minimum Comms Transmit Delay 0 to 250 ms 2 ms RW Num US
M05 Silent Period 0 to 250 ms 0 ms RW Num US
M06 Reset Serial Communications Off (0) or On (1)
RW Bit ND NC
M07 Keypad Port Serial Address 1 to 16 1 RW Num US
RW Read / Write RO Read-only Bit Bit parameter Txt Text string Date Date parameter Time Time parameter
Chr
Character
parameter
Bin Binary parameter IP IP address Mac MAC address Ver Version number SMP
Slot, menu,
parameter
Num Number parameter DE Destination ND No default value RA Rating dependent NC Non-copyable PT Protected
FI Filtered US User save PS Power-down save
M01 Serial Address
Mode Open-Loop, RFC-A, RFC-S
Minimum 1 Maximum 247
Default 1 Units
Type 8 Bit User Save Update Rate Read on serial communications reset
Display Format Standard Decimal Places 0
Coding RW, BU
M02 Serial Mode
Mode Open-Loop, RFC-A, RFC-S
Minimum 0 Maximum 15
Default 0 Units
Type 8 Bit User Save Update Rate Read on serial communications reset
Display Format Standard Decimal Places 0
Coding RW, Txt
Value Text
08 2 NP
18 1 NP
28 1 EP
38 1 OP
48 2 NP M
58 1 NP M
6 8 1 EP M
78 1 OP M
87 2 NP
97 1 NP
10 7 1 EP
11 7 1 OP
12 7 2 NP M
13 7 1 NP M
14 7 1 EP M
15 7 1 OP M
