304 E300 Design Guide
Issue Number: 1
8.7 Menu H: Configuration
Parameter
Range(Ú)Default(Ö)
Type
Open-Loop RFC-A RFC-S
Open-Loo
p
RFC-A RFC-S
H01 User Security Code 0 to 2147483647
RW Num ND NC PT US
H02 User Security Status
Menu 0 (0), All Menus (1), Read-only Menu 0 (2),
Read-only (3), Status Only (4), No Access (5)
RW Txt ND PT
H03 Security Status None (0), Read-only (1), Status-only (2), No Access (3)
RO Txt ND NC PT PS
H04 Default Drive None (0), Standard (1), US (2) None (0) RW Txt NC
H06
Output Phase Loss Detection
Enable
Disabled (0), Enabled (1) Enabled (1) RW Txt US
H07
Output Phase Loss Detection
Time
0.5s (0), 1.0s (1), 2.0s (2), 4.0s (3)
0.5s (0) RW Txt US
H08
Input Phase Loss Detection
Mode Enable
Full (0), Ripple Only (1), Disabled (2) Full (0) RW Txt US
H09 Direct To Floor Sensor Mode
Spd IP (0), Stop IP (1),
Spd IP+User Dist (2)
Spd IP (0)
RW Txt US
H10 Direct To Floor Edge Detection
Rising 1st (0), Falling 1st (1) Rising 1st (0) RW Txt US
H11 Control Input mode
Analog Run Prmit (0),
Analog 2 Dir (1), Priority 1 Dir (2),
Binary 1 Dir (3), Priority 2 Dir (4),
Binary 2 Dir (5), Control Word (6)
Priority 1 Dir (2) RW Txt US
H12 Direction Input Invert Off (0) or On (1) Off (0) RW Bit US
H13 Velocity Threshold 1 0 to 10000 mm/s 300 mm/s RW Num US
H14 Velocity Threshold 2 0 to 10000 mm/s 300 mm/s RW Num US
H15
Maximum Speed Error
Threshold
0 to 10000 mm/s 100 mm/s RW Num US
H16
Maximum Distance Error
Threshold
0 to 10000 mm 100 mm RW Num US
H17 Current Controller Mode
Off (0) or On (1) Off (0) RW Bit US
H18 Fan Maximum Speed ±10 10 RW Num US
H19 Elevator Control Mode
Creep To Floor (0),
Direct To Floor (1)
Creep To Floor (0) RW Txt US
H20 Fast Start Enable
Off (0) or On (1) Off (0) RW Bit US
H21 Fast Start Monitoring Distance
0 to 10000 mm 200 mm RW Num US
H22 Short Floor Landing Enable
Off (0) or On (1) Off (0) RW Bit US
H23 Floor Sensor Correction Enable
Off (0) or On (1) Off (0) RW Bit US
H24
Floor Sensor Correction Source
Select
Floor Sensor IP (0),
Creep Spd IP (1)
Floor Sensor IP (0) RW Txt US
H25
Floor Sensor Correction Edge
Detection
Rising 1st (0), Falling 1st (1) Rising 1st (0) RW Txt US
H26 Fast Stop Enable Off (0) or On (1) Off (0) RW Bit US
H27 Rapid Slow Down Enable Off (0) or On (1) Off (0) RW Bit US
H28 Freeze Protection Threshold -10 to 0 °C 0 °C RW Num US
H29 Normal Duty Enable Off (0) or On (1) Off (0) RW Bit US
H30 Position Display Mode
Relative (0), Absolute (1) Relative (0) RW Txt US
H31 Elevator Trip Disable Trips Enabled (0), Trips Disabled (1) Trips Enabled (0) RW Txt
H32 Date/Time Selector
Set (0), Powered (1), Running (2), Acc Powered (3),
Local Keypad (4), Remote Keypad (5), Slot 1 (6),
Slot 2 (7), Slot 3 (8), Slot 4 (9)
Powered (1) RW Txt US
H33 Date Format Std (0), US (1) Std (0) RW Txt US
H34 Turn On delay 200 to 65535 ms 200 ms RW Num US
H35 Standby Mode Enable Off (0) or On (1) Off (0) RW Bit US
H36 Standby Mode Mask 0000000 to 1111111 0000000 RW Bin US
H37 Reset Energy Meter Off (0) or On (1) Off (0) RW Bit
H38
Blocked Elevator Release
Enable Input
Off (0) or On (1) Off (0) RW Bit US
H39
Parameter Displayed At
Power-up
A00 to A80 A06 RW Num PT US
H40 Drive Name Characters 1-4 -2147483648 to 2147483647 0 RW Num PT US
H41 Drive Name Characters 5-8 -2147483648 to 2147483647 0 RW Num PT US
H42 Drive Name Characters 9-12 -2147483648 to 2147483647 0 RW Num PT US
H43 Drive Name Characters 13-16 -2147483648 to 2147483647 0 RW Num PT US
H45 Action On Trip Detection 00000 to 11111 00000 RW Bin US
H46 Number Of Auto reset Attempts None (0), 1 (1), 2 (2), 3 (3), 4 (4), 5 (5), Infinite (6) None (0) RW Txt US
H47 Auto-reset Delay 1.0 to 600.0 s 1.0 s RW Num US
